Basic Data
Material: Polyamide 6.6 (PA66)
Flammability: UL94 V2
Properties: Acid resistance, corrosion resistance, good insulation, not easy to age, strong endurance.
product category:Internal tooth tie
Is it reuasable: no
Installation temperature: -10℃~85℃
Working Temperature: -30℃~85℃
Color: The standard color is natural(white) color, which is suitable for indoor usage;
The black color cable tie added the carbon black and UV agent, which is available for outdoor usage.
SPECIFICATION
| ITEM No. | Specification(WxL) (mm) | Effective Length (mm) |
MAX.BUNDLE DIA. (mm) |
TENSILE STRENGTH (STANDARD) |
||
| Width(mm) | Length(mm) | |||||
| Lbs | Kgs | |||||
| SY1-2-4150 | 4 | 150 | 120 | 35 | 40 | 18 |
| SY1-2-4200 | 200 | 170 | 50 | |||
| SY1-2-5250 | 5 | 250 | 200 | 65 | 50 | 22 |
| SY1-2-5300 | 300 | 260 | 80 | |||
| SY1-2-7145 | 7 | 145 | 115 | 35 | 112 | 50 |
| SY1-2-7175 | 175 | 145 | 45 | |||
| SY1-2-7200 | 200 | 170 | 50 | |||
| SY1-2-7240 | 240 | 200 | 60 | |||
| SY1-2-7300 | 300 | 260 | 80 | |||
| SY1-2-7400 | 400 | 360 | 110 | |||
| SY1-2-10300 | 10 | 300 | 260 | 80 | 124 | 55 |
| SY1-2-10350 | 350 | 310 | 95 | |||
| SY1-2-10400 | 400 | 360 | 110 | |||
| SY1-2-10450 | 450 | 410 | 130 | |||
| SY1-2-10550 | 550 | 510 | 160 | |||
| SY1-2-10600 | 600 | 560 | 175 | |||
Highly Recommend
Super durable and super strong, presenting The Black Zip Ties with Metal Tooth Stainless Steel Locking Device.
The highest tensile strength at the lowest temperatures. The innovative locking system with over-molded stainless-steel grants superior mechanical performances than any other cable tie on the market.
